Single Table Laser Cutting Machine

A single-table laser cutting machine uses a high-powered laser beam to cut materials with precision. The workpiece is placed on a stationary table, while the laser head moves along the X and Y axes to perform cuts. This setup ensures accuracy, speed, and versatility for cutting metals, plastics, and other materials.

  • single-tble-laser-cutting-machine
  • single-tble-laser-cutting-machine
Single Table Laser Cutting Machine
Batch continuous processing
Single Table Laser Cutting Machine
Fast speed and low energy consumption
Single Table Laser Cutting Machine
Easy to operate

Introduction to Configuration

  • Stretched Aluminum Gantry
    Stretched Aluminum Gantry

    Using low pressure steel film casting process,the beam has high density, light weight,smooth surface quality,excellent integrity and rigidity.At the same time,it has good toughness,ductility and corrosion resistance.

  • Super Thick and Wide Steel Bed
    Super Thick and Wide Steel Bed

    Steel bed has good shock absorption and small deformation, which ensures the stability of long-term production.It can effectively counteract the force of frequent high-speed reversing and high acceleration and deceleration,which is the guarantee of stable quality and provides support for constant quality of laser cutting machine.

  • Laser Cutting System
    Laser Cutting System

    Intelligent visual control system, the operation interface is easier to understand, and the laser power, gas type and pressure can be adjusted intuitively; Intelligent edge searching, automatic positioning, easy to achieve efficient production.

  • Japan Panasonic Servo Motor
    Japan Panasonic Servo Motor

    The high precision servo motor can control the cutting speed and position, running smoothly and without vibration.

  • Laser Cutting Head
    Laser Cutting Head

    The laser head automatically avoids obstacles, suppresses vibrations, and enables multiple perforation patterns.

Details of Single Table Laser Cutting Machine






Specification of Single Table Laser Cutting Machine

ModelFIBER-3015 SeriesFIBER-4015 SeriesFIBER-4020 SeriesFIBER-6015 SeriesFIBER-6020 SeriesFIBER-6025 SeriesFIBER-8025 Series
Processing range3000*1500mm4000*1500mm4000*2000mm6000*1500mm6000*2000mm6000*2500mm8000*2500mm
X-axis travel1500mm1500mm2000mm1500mm2000mm2500mm2500mm
Travel Y-axis3000mm4000mmm4000mm6000mm6000mm6000mm8000mm
Z-axis travel140mm140mm140mm140mm140mm140mm140mm
laser powwer1000/1500/2000/3000/4000/6000/8000/10000/12000/15000/20000W/other
X/Y axis positioning accuracy≤±0.03mm/min
X/Y axis repeatsd positioning accuracy≤±0.02mm/min
Max positioning speed120m/min
